Gas Spring Selection Guide: A 2026 Engineering Overview

Selecting a gas spring requires calculating the specific force load, determining the necessary stroke length, and verifying the mounting geometry to match your application requirements. As an engineer, I often see critical failures caused by simple oversights in these parameters, leading to equipment damage or injury.

How Do I Calculate the Required Force for a Gas Spring?

Required force is determined by the total weight of the lid, the distance of the center of gravity from the pivot, and your mounting points.

What is the basic force calculation formula?

The force per spring is calculated as (Weight x Distance to CG) divided by (Number of springs x Distance from pivot to mount).

To start, you must define the weight of your lid or panel and locate its center of gravity. For most rectangular panels, this is exactly at the geometric center.

Once you establish the distance from the pivot hinge to the center of gravity, you apply the lever arm calculation. Always remember to factor in the specific mounting position you intend to use for the spring base.

• Weight of the panel (N)
• Distance to center of gravity (mm)
• Distance from hinge to spring mount (mm)
• Number of springs used

Why should I include a safety margin in my force estimate?

A 15-20% safety margin compensates for initial nitrogen gas permeation and reduced operating temperatures in outdoor environments.

Nitrogen is a gas and it will naturally migrate through seals over time. Specifying a spring at the absolute minimum force calculation will lead to premature failure as soon as that slight degradation occurs.

Furthermore, check out our gas spring force calculator to verify your design parameters. It accounts for these variances to help prevent specifying an undersized part that leaves your hatch drifting closed.

How Do I Determine the Correct Stroke and Compressed Length?

Stroke is the difference between extended and compressed lengths, which must be verified against your lid’s physical opening arc.

How do I measure stroke length accurately?

Measure the distance between mounting points when the lid is closed and fully open, then subtract the difference for your stroke.

I advise building a basic geometry model in CAD or a physical mockup. Do not simply measure the lid travel in degrees as this ignores the arc swept by the gas spring itself.

What happens if I choose the wrong compressed length?

An incorrect compressed length will cause the gas spring to bottom out or prevent the lid from closing fully, risking structural damage.

Always verify the manufacturer’s data sheet for the closed length of the specific part number. If your available space is tighter than the spring allows, you must adjust your bracket positions.

What End Fittings and Mounts Should I Use?

End fittings must be selected based on the load requirements and the vibration levels of the target application environment.

When is a ball socket fitting the right choice?

Ball socket fittings allow for 360-degree rotation and some misalignment, making them ideal for light-duty cabinet and trunk applications.

These fittings are the industry standard for most automotive and furniture tasks. They offer easy installation and removal without specialist tools.

Why should I specify stainless steel end fittings?

Stainless steel fittings provide essential corrosion resistance for marine, coastal, or high-humidity industrial environments.

For more detailed information on specific environments, read our guide on marine-grade stainless steel gas struts to ensure long-term reliability. Using zinc-plated components in these areas will lead to seizure and failure within months.

Frequently Asked Questions

Can I refill a gas spring if it loses pressure?

No, gas springs are factory-sealed units and cannot be recharged or repaired if they lose pressure due to seal fatigue.

Should I always replace gas springs in pairs?

Yes, replacing only one spring creates an uneven load, causing the new spring to work harder and fail significantly faster than normal.

Can I mount a gas spring at any angle?

Most gas springs should be mounted rod-end down to ensure the internal oil stays in contact with the seals for proper damping.

What type of gas spring should I choose for my application?

Select extension, compression, or lockable gas springs based on whether you need to assist opening, assist closing, or hold a position at any point in the travel.

Extension (lift‑assist) springs generate force when they extend, making them ideal for lids, doors, or panels that need help opening and staying open. They are commonly used on toolboxes, truck tailgates, and access covers where the spring pushes the lid upward.

Compression (push‑assist) springs produce force when they compress, suited for applications that require assistance in closing or holding a lid down, such as oven doors, equipment guards, or safety covers. Lockable gas springs incorporate a valve that can lock the piston at any position, providing variable hold‑off strength for adjustable workbenches, medical tables, or convertible furniture where intermittent locking is required.
