The Definitive Gas Springs Guide for UK Engineers (2026)

Selecting the correct gas spring is critical for the reliable and safe operation of countless mechanical systems. As an industrial engineer with 18 years of experience specifying these components across the UK and European markets, I understand the nuances involved. This guide aims to demystify the process, ensuring you specify the right gas spring for your application, avoiding common pitfalls and costly errors.

How Do I Select the Right Gas Spring Force?

Gas spring force is primarily dictated by lid weight, hinge geometry, and mounting points, not just total lid size.

What is the correct force rating for a gas spring?

The force rating, typically expressed in Newtons (N), is the fundamental specification for any gas spring. It denotes the force required to compress the spring, measured under standard laboratory conditions at mid-stroke (usually 20°C or 68°F). This rating is crucial because it dictates the spring’s ability to lift, counterbalance, or hold open a lid, hatch, or panel against gravity and any other opposing forces.

When specifying a gas spring, it’s vital to understand that the effective force varies throughout the extension stroke. The force is higher when the spring is compressed and lower when fully extended. For most applications, the mid-stroke rating serves as the primary design parameter. However, understanding this variation is key to preventing issues such as lids not holding open at their maximum angle or slamming shut unexpectedly.

How does lid weight and geometry affect required force?

The weight of the panel or lid is the most significant factor in determining the required gas spring force. However, geometry plays an equally critical role. The distance of the lid’s centre of mass from the hinge axis, and the distance of the gas spring’s mounting points from the hinge, fundamentally alter the torque applied by the lid and the leverage the gas spring can exert.

A heavier lid requires a higher force spring. Similarly, if the gas spring is mounted very close to the hinge, it will have less leverage and require a higher force rating than if it were mounted further away. Conversely, a spring mounted further out will have more leverage and might require a lower force rating. Incorrectly assessing these geometric factors is a common reason for specifying an undersized or oversized spring.

How do I calculate the required gas spring force?

Calculating the required force usually involves a torque balance equation. Simplified formulas can be used, particularly for lids opening horizontally. For a single gas spring assisting a lid that opens upwards from a horizontal position, the basic formula is:

Metric Formula (N)	Imperial Formula (lbf)
F = (W × d1) / (d2 × N)	F = (L × d1) / (d2 × N)

Where:

• F = Required force per spring (N or lbf)
• W = Weight of the lid (N) or L = Weight of the lid (lbs)
• d1 = Distance from the hinge axis to the lid’s centre of mass (mm or inches)
• d2 = Distance from the hinge axis to the gas spring’s mounting point on the lid (mm or inches)
• N = Number of gas springs used (typically 2 for lids, 1 for hatches)

It is prudent to add a margin of 10-20% to your calculated force to account for factors such as friction in the hinge, the spring’s performance at lower operating temperatures, and gradual force loss over time. Always verify your calculations with a method that accounts for the specific geometry of your application. Numerous online calculators, including our own Aritech Gas Spring Force Calculator, are available to simplify this process.

What is the Correct Stroke Length for a Gas Spring?

Stroke length is the distance the gas spring rod extends or retracts, and must match the application’s range of motion.

How is stroke length defined?

The stroke length of a gas spring refers to the linear distance the piston rod travels between its fully compressed and fully extended positions. It’s a critical dimension that directly affects how far open or closed your lid, hatch, or panel will move. The stroke is measured in millimetres (mm) in metric specifications and inches in imperial specifications.

The stroke length is intrinsically linked to the compressed and extended lengths of the gas spring. Specifically, the extended length is equal to the compressed length plus the stroke length (Extended Length = Compressed Length + Stroke Length). Choosing the correct stroke ensures the gas spring neither bottoms out prematurely nor fails to achieve the desired fully open or fully closed position.

How do I determine the required stroke length for my application?

Determining the required stroke length involves understanding the full range of motion of the component the gas spring will operate. This is not simply the total travel distance of the lid in degrees but the linear path the gas spring’s end fittings will trace.

The most accurate method involves modelling the desired motion in CAD software. You will simulate the movement of the lid or panel from its closed position to its fully open position, plotting the distance between the gas spring’s upper and lower mounting points. The difference between the maximum and minimum distances observed during this simulation represents the required stroke length. This geometric approach accounts for the arc of motion and the specific placement of the mounting hardware.

Alternatively, if CAD modelling is not feasible, you can measure the distance between the mounting points on a similar, correctly functioning application. Measuring the spring in its fully compressed and fully extended states provides its compressed and extended lengths, from which the stroke can be derived. Always add a small buffer, typically 10-15%, to the calculated stroke to ensure full travel and prevent the spring from being stressed at its extreme limits.

What is the difference between extended length and compressed length?

The extended length of a gas spring is the total length of the unit when the piston rod is fully deployed, and the spring is exerting its minimum resistance. This is typically measured from the centre of the connection point on one end to the centre of the connection point on the other, or to the end of the rod at the sealing point, depending on the fitting type.

The compressed length, conversely, is the total length of the unit when the piston rod is fully retracted into the cylinder. This is the dimension the gas spring will occupy when the lid or panel is fully closed. The difference between the extended length and the compressed length is the stroke length. It is essential to ensure that the compressed length of the chosen gas spring will fit within the available space when the lid is in its closed position, with adequate clearance to avoid obstruction.

What are the Key Mounting Considerations for Gas Springs?

Proper mounting geometry significantly impacts gas spring performance, longevity, and safety, influencing force and stroke effectiveness.

How does mounting position affect gas spring performance?

The position where you mount your gas springs relative to the hinge is paramount. As mentioned in the force calculation section, the distance from the hinge axis to the gas spring’s mounting point on the lid (d2) is a critical variable. Locating the mounting point further away from the hinge axis increases the leverage available to the gas spring, allowing it to exert more torque for a given force rating. This can enable the use of a lower-force, and potentially shorter-stroke, gas spring.

Conversely, mounting the gas spring closer to the hinge axis reduces its leverage. To achieve the same lifting or holding power, a higher force rating would be necessary. More importantly, mounting position affects how the spring engages over its stroke. For instance, mounting the gas spring too close to the hinge, or at an unfavourable angle, can lead to the spring not having sufficient leverage to overcome the lid’s static weight when nearly closed, or it may struggle to hold the lid open at its maximum angle.

What are the different types of gas spring end fittings?

Gas springs terminate in various end fittings, each designed for specific mounting requirements and application dynamics. Understanding these types is essential for a secure and effective installation:

• Ball Socket: The most common type, featuring a socket that clips onto a ball stud. They offer quick, tool-less connection and disconnection, making them ideal for applications requiring frequent access or maintenance. Standard sizes include 10mm and 8mm. They allow for some degree of misalignment but are susceptible to wear in high-vibration environments.
• Clevis Bracket: This fitting consists of a U-shaped bracket that attaches to the spring body, with a hole for a pin or bolt. Clevis fittings provide a more robust, pinned connection, suitable for applications with significant vibration or shock loads. They generally offer better resistance to detachment compared to ball sockets.
• Eyelet: A simple loop or eye at the end of the rod or body, designed to be bolted through directly to the mounting bracket. While straightforward, they require precise alignment and are less common in standard off-the-shelf gas springs, often being part of custom solutions.
• Threaded Boss: Some gas springs feature a male or female thread at the end of the rod or body. This allows for direct screwing into a threaded mounting point or the attachment of alternative connectors. It’s also seen in adjustable springs where turning a threaded rod can alter the gas pressure and thus the force.

The choice of end fitting dictates the type of mounting hardware required and influences the ease of installation and long-term reliability of the assembly.

What is the standard orientation for mounting gas springs?

The recommended mounting orientation for most standard gas springs is with the piston rod pointing downwards. This orientation ensures that the internal hydraulic fluid consistently lubricates the seal and the rod surface. This lubrication is critical for maintaining the integrity of the seal, preventing gas leakage, and ensuring the longevity of the gas spring.

Mounting with the rod pointing upwards can lead to the seal drying out over time, degrading its sealing properties and causing premature loss of force. In applications where rod-down mounting is not possible, specific gas spring designs, often termed ‘universal’ or ‘any-angle’ mounting types, are available. These may incorporate features to ensure continuous sealing regardless of orientation, but it is always best to consult the manufacturer’s datasheet for specific orientation guidelines and limitations. Horizontal mounting is generally acceptable, provided the internal oil reservoir is correctly positioned to maintain seal lubrication.

What are the common applications for gas springs?

Gas springs are used across automotive, furniture, marine, and industrial sectors for controlled lifting, counterbalancing, and soft-closing.

Where are gas springs used in the automotive industry?

In the automotive sector, gas springs are ubiquitous, assisting with the controlled opening and closing of various vehicle access points. They are most commonly found in the boots (trunks) and bonnets (hoods) of passenger cars and commercial vehicles, providing effortless lift and ensuring the access panel stays securely open. This application is familiar to most vehicle owners. My experience confirms that many vehicles from the late 2000s onwards were fitted with marginally specified bonnet struts due to weight-saving requirements; an uprate of 20-30% is often beneficial and safe.

Beyond boots and bonnets, gas springs are also employed in the tailgates of SUVs and estate cars, rear van doors, and even within convertible roof mechanisms to counterbalance the weight of the roof panels. Some aftermarket applications include support for spare wheel covers or toolboxes on trucks and utility vehicles. For any automotive application, especially in the UK, it is imperative to select gas springs with corrosion-resistant end fittings, such as stainless steel, due to exposure to road salt and moisture. We always recommend replacing automotive struts in pairs, as the wear and tear on both is usually similar.

How are gas springs used in furniture and cabinetry?

The furniture and cabinetry industry relies heavily on gas springs for enhanced functionality and user experience. In kitchens, they are essential for overhead cabinet doors, providing smooth lift-up motion, soft-closing capabilities, and the ability to hold doors open at any chosen angle, preventing them from banging against ceilings or other cabinets. For instance, cabinet lift stays are crucial for overhead kitchen cabinets, where a standard 80-100N force rating is often more suitable for taller doors compared to the 60N commonly found on budget units, ensuring reliable operation over years.

Ottoman beds, which feature integrated storage beneath the mattress, are another major application. Gas struts help the lifting of the heavy mattress base, providing easy access to the storage compartment below. The common failure point here is often the pivot pin mechanism rather than the strut itself; ensuring the mechanism is sound is key. In custom furniture, such as TV lift mechanisms integrated into media consoles or beds, gas springs provide the controlled vertical movement. For applications like loft hatches, standard gas struts rated appropriately for the hatch weight and size are invaluable for making them easy to open and close safely.

What are the industrial and marine applications for gas springs?

In industrial settings, gas springs are used for a wide array of purposes requiring controlled movement and load balancing. They are found on machine guards, enabling safe and easy access for maintenance while ensuring the guard remains open. They are also used in agricultural machinery on engine covers, toolboxes, and access panels; specify stainless steel for marine applications due to their superior corrosion resistance. Unlike standard carbon steel springs, 316 stainless steel units will withstand harsh marine environments without significant degradation, costing 3-4 times more but providing vastly extended service life.

For specialized industrial equipment, such as medical devices, laboratory enclosures, or server rack access panels, gas springs provide smooth, controlled operation. In marine applications, they are crucial for boat engine hatches, companionway covers on sailboats, and locker lids, where resistance to saltwater corrosion is paramount. For these environments, 316 stainless steel gas springs are practically a necessity, often specified with 10mm minimum rod diameters for enhanced durability. Boat hatches at sea often experience angles different from when docked, so overrating by 25-30% compared to land-based equivalents is advisable.

How do I troubleshoot and maintain gas springs?

Common gas spring issues include gradual force loss, and improper operation due to incorrect sizing or mounting. Maintenance is minimal, focused on external inspection.

Why is my gas spring losing force?

The most common reason for a gas spring losing force is a slow leakage of the nitrogen gas through the piston rod seal over time. This is a natural process of wear and tear, exacerbated by environmental factors and the frequency of operation. As the internal pressure drops, the spring’s ability to counterbalance weight diminishes, resulting in lids or panels that do not stay open fully or require more effort to lift.

Another significant factor is temperature – gas springs lose approximately 1.5% of their force for every degree Celsius below their rated operating temperature. If a lid that works perfectly in summer fails to stay open in winter, it is likely due to temperature-induced force reduction rather than a faulty spring, assuming the spring is within its service life. Sudden loss of force can indicate severe seal damage or a fracture in the cylinder. In such cases, the gas spring cannot be recharged and must be replaced.
